Plastic Hose Extrusion Line
PVC/TPU lay flat hose extrusion line
Use：
Hi-strength terylene yarn and qualified PVC synthesis materials.
Light weight,good flexibility ,bright color,smooth smearing layer.
Flat roll and easy fortake back,convenient for moving and non limitation for length.
Capable for keeping the flexibility and elasticity under the low-temeraturre water.
Anti-hi pressure ,corrosion resistace and ageing resistance.
Applied to the lines of the auxiliaries for agricultural tools against the drought,project,mining ,environment protection,industry and so on,which is the most ideal liquid-transferred hi-pressure hose.
Applicable operation temperature 10°-60°specifications:20-300mm.
Main Technical Parameters:
设备技术参数
| MODEL | JD55 | JD65 | JD75 | JD90 | JD90*2 |
|---|---|---|---|---|---|
| EXTRUDER | SJ55/35 | SJ65/35 | SJ75/35 | SJ90/35 | SJ90/35*2 |
| DIAMETER RANGE(MM) | 25-38 | 50-75 | 50-150 | 100-200 | 200-300 |
| OUTPUT(KG/H) | 30-50 | 40-60 | 60-90 | 80-120 | 120-200 |
| INSTALLED POWER(KW) | 50 | 60 | 80 | 100 | 130 |
